Accessories and miscellaneous

The Townet 300-30-SU CPE uses MIMO technology on the 5 GHz band (802.11n and HiperLAN2) with an integrated 20 dBi polarized dual-slant panel antenna, for throughput up to approximately 300 Mbps and coverage in point-to-multipoint environments.

The system consists of an outdoor unit (ODU) in an IP67 UV-stabilized nylon enclosure, and an indoor unit (IDU) powered via Ethernet (PoE or DC 18-24 V) via a single external Cat-5 FTP cable, simplifying cabling and installation even in rural or condominium settings. It is compatible with power from renewable sources and consumes less than 6 W.

The CPE supports the proprietary Townet XPlode protocol for optimized performance in P-MP systems. It features advanced bridging, routing (IPv4/IPv6, STP, OSPF, BGP, MPLS, HWMP+), security (WEP/WPA/WPA2, IPsec, RADIUS), QoS, VLAN, VPN, management via SNMP, SSH, GUI and support for advanced VLAN and QoS layer 2-7.

• Radio Band: 5 GHz HiperLAN2 / IEEE 802.11n
• Maximum Speed: up to 300 Mbps
• Antenna: Built-in 20 dBi dual-slant
• Unit: IP67 ODU + IDU powered PoE/DC 18-24 V
• Consumption: < 6 W, also powered by 12/24 V batteries
• Bridge/routing: IPv4/IPv6 support, STP/RSTP, OSPF, BGP, MPLS, HWMP+
• Security: WEP, WPA/WPA2, AES, IPsec, RADIUS, firewall
• QoS and VLAN: layer 2-7, VLAN 802.1q, inter-VLAN routing, QinQ
• Management: GUI, SSH, Telnet, SNMP v1/2
• Proprietary protocol: Townet XPlode
• Environmental protections: IP67, solar radiation ASTM G53, salt fog 500 h
• Power consumption: 18-24 V DC or optional PoE/48 V
• Operating Temperatures: ODU -40 °C / +65 °C, IDU 0 °C / +45 °C
• Dimensions & Weight: 250 x 250 x 77 mm, 1.7 kg

The Townet 900-20-BS 5GHz 802.11ac MIMO Base Station is designed for high-performance wireless connections in point-to-multipoint scenarios. It operates in the 5GHz band with a maximum speed of 866Mbps and adopts the ETSI HiperLAN2, IEEE 802.11a, and 802.11ac standards, with OFDM/TDD technology and channels up to 80MHz.

With a gigabit Ethernet port and 2x2 MIMO support, it ensures high performance and network stability. It offers comprehensive IPv4/IPv6 bridging, VLAN, advanced routing, VPN, firewall, and QoS features. The IP68-rated enclosure and environmental resistance make it suitable for demanding outdoor applications.

• Radio Band: 5GHz, HiperLAN2 standard, 802.11a/ac
• MIMO: 2x2
• Speed: up to 866Mbps
• Ethernet: 1à—autosensing gigabit RJ45 port
• Network Features: bridging, VLAN, routing (static, OSPF, BGP, MPLS), HWMP+ mesh
• Security: WPA2, AES, RADIUS, IPsec, firewall
• QoS: layer2 7 traffic shaping, CBQ
• Power supply: 12 24V DC or 48V PoE (802.3af-AC), max 17W
• Protection rating: IP68, 25kV lightning protection
• Operating temperature: ODU: -40°C/+65°C; IDU: 0°C/+50°C
• Dimensions: 214à—149à—75mm; weight: 1.4kg

The Townet 900-40-SU 5GHz 802.11ac MIMO CPE radio is a high-performance solution for stable wireless connections in outdoor environments. It operates in the 5GHz band with speeds up to 866Mbps and integrates a 24.5dBi dual-slant antenna with a 9°à—9° aperture, ideal for point-to-multipoint scenarios.

It supports ETSI HiperLAN2 and IEEE 802.11a/ac standards, channels up to 80MHz, and OFDM/TDD modulation. Networking features include IPv4/IPv6 bridging, static and dynamic routing (OSPF, BGP, MPLS, HWMP+ mesh), Layer 2 7 QoS, VLAN, IPsec VPN, RADIUS authentication, and firewall. Manageable via web GUI, SSH, Telnet, HTTPS and SNMP v1/2/3.

Designed to withstand harsh environments, it features an IP68 enclosure, lightning protection up to 16kV, resistance to salt fog and UV radiation. It is powered via PoE 30VDC (optional 802.3af compatible), with a maximum consumption of 10W. Compact and lightweight, it is ideal for professional outdoor installations.

• Band: 5GHz, HiperLAN2 standard, 802.11a/ac
• Speed: up to 866Mbps
• Antenna: integrated dual slant 24.5dBi (9°à—9°)
• Bridge and routing: IPv4/IPv6, STP, RSTP, OSPF, BGP, MPLS, HWMP+
• QoS: Layer 2 7, traffic shaping, CBQ
• VPN and security: WPA2, AES, IPsec, RADIUS, firewall
• VLAN: 802.1q, QinQ, inter-VLAN
• Management: GUI, SSH, Telnet, HTTPS, SNMP v1/2c/3
• Protection: IP68, 16kV lightning protection, salt fog, UV radiation
• Power supply: PoE 30VDC, max 10W
• Dimensions: 312 à— 312 à— 74mm; weight 1.3kg

The Smartbox 864 Wh LiFePO4 battery pack is a dedicated solution for Smartbox, designed to provide power with a capacity of 72 Ah and management via an integrated BMS. Thanks to LiFePO4 technology, the Townet product is suitable for contexts where operational continuity, battery control, and integration with Smartbox systems are required.

The configuration with a nominal energy of 864 Wh allows it to support professional applications with a dedicated energy reserve. The integrated BMS contributes to battery pack management, making this Townet solution suitable for installations requiring a specific storage system for Smartbox.

• Battery pack for Smartbox.
• LiFePO4 technology.
• Capacity of 72 Ah.
• Nominal energy of 864 Wh.
• Integrated BMS.

The Hikvision thermal camera blackbody is a critical tool for accurate measurements in body temperature detection applications. It operates within a range of 35-60°C, with a temporal stability of 0.1-0.2°C/h and an emissivity of 0.97 ± 0.02, ensuring a stable thermal reference.

The uniform 78 - 78 mm emitting surface provides a consistent source for calibrating Hikvision temperature monitoring cameras. Powered by 220-240 VAC with a maximum consumption of 20 W, it can be placed on a flat surface or mounted on a tripod thanks to the standard 1/4-20 UNC connection.

• Temperature range: 35-60 °C
• Accuracy: ± 0.2 °C
• Stability: ± 0.1-0.2 °C/h
• Emissivity: 0.97 ± 0.02
• Emission area: 78 - 78 mm
• Power supply: 220-240 VAC, max. 20 W
• Surface or tripod installation (1/4-20 UNC connection)
• Compatible with thermal cameras Hikvision for temperature detection

The Hikvision industrial switch is designed for harsh environment applications requiring stable connectivity, advanced PoE power, and extensive resistance to extreme temperatures. Equipped with 8 Gigabit PoE ports and 2 SFP ports, it supports Hi-PoE power up to 90W on the first two ports and a total power budget of 110W, offering an efficient solution for devices such as cameras and industrial equipment. The metal enclosure with fanless design and surge protection make it suitable for demanding installations. Key Features

• 8 Gigabit PoE ports and 2 Gigabit SFP ports
• Hi-PoE up to 90 W on ports 1-2
• IEEE 802.3af, 802.3at, and 802.3bt support
• 110 W total PoE budget
• Operating temperature range: -40°C to 75°C
• 6 kV surge protection
• Metal enclosure with fanless design
• Desktop or DIN-rail installation
• 20 Gbps switching capacity and 1.5 Mbit internal cache

The 1,344 Wh UPS standalone power supply unit is designed to provide power continuity in applications where system reliability is critical. With this solution, EnergyStock offers a highly efficient power supply unit with a 1,344 Wh LiFePO4 battery and a microprocessor-based BMS, designed to power loads even during prolonged power outages and to operate both as a UPS and in streetlight mode.

The structure integrates an air extraction system with a 60 mm fan driven by an internal temperature probe and managed by a microprocessor, dust filters, external stainless steel filters, and air inlet and outlet chimneys complete with insect screens. The cabinet is equipped with a key lock, IP65 protection rating, IP44 ventilated and IK10 resistance.

This unit is suitable as a backup for cameras that must always remain operational in the absence of the main power supply, for example in license plate reading systems, sanctioning systems, high-security video surveillance and traffic control. Standard alarm outputs are also available for low battery level, fan stop and 230 Vac power failure, as well as a serial output and DIN rail for mounting accessories up to 17 modules.

Main features

• 1,344 Wh LiFePO4 battery
• Over 2,000 charge and discharge cycles with 80% DoD
• Lamppost cycle operation
• Also functions as a UPS on battery output
• Microprocessor BMS
• Input 90-264 Vac
• Output 12.2-14.7 Vdc
• 60 mm fan with air exchange of 44.62 m3/h
• 7 M20x1.5 cable glands with IP68 protection
• External filters Stainless steel
• Operating temperature from -20 °C to +55 °C
• Dimensions 350 x 446 x 205 mm
• Weight 18 kg plus pole support
• Protection rating IP65, IP44 ventilated and insulation compliant with Class II
• Maximum load for street lamp use 75 W with 17 hours of light
• Recharging time 8 h 10 m with 20 A power supply and 75 W load
• Maximum load for UPS use 150 W
• Autonomy up to 8 h 28 m
• Recharging time 12 h 03 m with 20 A power supply and 150 W load
• Standard alarm outputs and serial output available
• DIN rail for accessories up to 17 modules

The stainless steel pole mount for EnergyStock ES020 series units is an accessory designed for pole installation of EnergyStock family units. The stainless steel structure makes it suitable for dedicated mounting of ES020 units, with indications for use on poles with a minimum diameter of 100 mm.

Within the EnergyStock range, this support offers a specific solution for fixing EnergyStock ES020 series units. For pole mounting, the use of 1/2" Band-IT tape or similar is recommended.

• Stainless steel pole mount
• Compatible with EnergyStock ES020 series units
• Installation on poles with a minimum diameter of 100 mm
• For pole mounting, 1/2" Band-IT tape or similar is recommended
• EnergyStock family accessory

The DC/DC converter for power supply units is an accessory from the EnergyStock family designed for integration into dedicated units. It offers 100 W of power, with an input voltage of 9 to 18 Vdc and an output voltage of 48 Vdc at 2.1 A, making it suitable for applications requiring power conversion in specific contexts.

The EnergyStock solution supports DIN rail mounting and is supplied assembled and wired in the units, simplifying installation. Extended operating temperature from -40°C to 70°C allows for use in environments with harsh operating conditions.

• 100 W DC/DC converter.
• Input voltage 9-18 Vdc.
• Output voltage 48 Vdc / 2.1 A.
• Extended operating temperature from -40°C to 70°C.
• DIN rail mounting support.
• Supplied assembled and wired in EnergyStock units.
• Accessory of the EnergyStock family.

The Townet Point-to-Point Bridge is a high-performance solution designed to ensure reliable connections even over very long distances, thanks to the 802.11ax radio standard and powerful integrated antenna. Speeds of up to 2.4Gbps enable intensive data transfer, while the IP68 rating makes it perfect for harsh outdoor environments. Power is provided via PoE or via DC 12-24V or 48V power supplies, offering flexibility in various configurations.

• 802.11ax 5GHz radio standard, also compatible with 802.11a/ac/Hiperlan2
• Integrated 26dBi antenna (24.5 dBi VPol / 25.5 dBi HPol)
• Maximum speed 2.4Gbps
• IP68 environmental protection, resistant to rain, dust, and atmospheric agents
• TCP/IP support with IPv4/IPv6 bridge, VLAN (802.1q, QinQ), static routing, RIP, OSPF, BGP, VPLS, MESH HWMP+
• Advanced SNMP, RADIUS, VPN (IPsec, PPTP, L2TP, EoIP), QoS Layer2 7, VLAN, firewalling
• Adjustable TX power up to 31dBm with ATPC ±3dBm, DFS and auto channel management
• Interfaces: 1à—RJ45 Gigabit Ethernet PoE, 2à—QMA(F) S/T antenna connectors
• Dimensions 370à—370à—220mm, weight approx. 3.45kg
• Maximum consumption 17W; DC 12-24V or 48V / AC 200-264V power supply
• Surge protection up to 25kV (EN61000-4-5) with magnetic filter and gas discharge tubes
• Operation from -40°C to +65°C (ODU); from 0°C to +50°C (IDU)

The Townet K30SU is a 5 GHz Point-to-Point CPE/Bridge based on Wi-Fi 6 (802.11ax) technology, designed for high-capacity and stable connections in outdoor wireless networks. The integrated 20 dBi antenna with dual slant polarization (10° x 10°) ensures efficient transmission up to 2.4 Gbps, guaranteeing high performance even over long distances.

The device supports bridge and routing modes with IPv4/IPv6, OSPF, BGP, MPLS and IPsec VPN protocols. It integrates advanced security features such as WPA2/WPA3, AES-256 and RADIUS authentication. Management is simple and versatile via web interface, SSH, SNMP or Wireless Controller. PoE power (8-30 V DC) and IP68 design make it resistant to dust, water, salt and solar radiation, perfect for demanding outdoor installations.

• Model: K30SU
• Wi-Fi 6 (802.11ax) technology - 5 GHz band
• Speed up to 2.4 Gbps
• Built-in 20 dBi antenna, dual slant 10° x 10°
• Adjustable transmission power 0-30 dBm
• Protocols: IPv4/IPv6, OSPF, BGP, MPLS, RIP, VPLS
• Security: WPA2/WPA3, AES-256, RADIUS, IPsec VPN
• Management via Web, SSH, SNMP v1/2/3, Wireless Controller
• Power supply PoE 8-30 V DC (802.3af optional)
• Maximum consumption 12 W - Protection IP68 - Range -40 °C / +65 °C
• Dimensions 250 x 250 x 77 mm - Weight 1.7 kg

The Townet K-40-SU 5GHz Wi-Fi 6 MIMO CPE Radio is an advanced solution for high-performance Point-to-Point connections in the 5GHz band. Thanks to the Wi-Fi 6 (802.11ax) standard, it supports throughput of up to 2.4Gbps and guarantees greater efficiency and stability even in congested environments.

It integrates a 24dBi dual-slant directional antenna designed for long distances, with excellent resistance to interference. The radio is completely sealed and IP68 certified, making it suitable for outdoor environments exposed to harsh environmental conditions.

• Radio Standard: Wi-Fi 6 (802.11ax), 5GHz band
• Speed: Up to 2.4Gbps
• Antenna: Integrated dual slant 24dBi
• Modes: CPE, Point-to-Point Bridge
• Protection: IP68 for outdoor use
